Steel Pipe

Short Description:


  • Standard: ASTM A106/ASME SA106
  • Material: A179, A178, A192, A334-04A
  • Length: 0-38000mm
  • WT: 0.5-30mm
  • Product Detail

    Product Tags

    Wall thickness:

    SCH10, SCH20, SCH30, STD, SCH40, SCH60, SCH80, SCH100 SCH120, SCH160, XS, XXS

    Description of Steel Pipe:
    Name seamless & welded carbon steel pipe
    Standard ASTM A106/ASME SA106 Gr.A,Gr.B, ASTM A178/ ASME SA178, ASTM A179/ ASME SA179, ASTM A192/ ASME SA192, ASTM A334/ ASME SA334-04a Gr 1, Gr.3, Gr.6, Gr.7, Gr.8, Gr.9, Gr.11, ASTM A209/ ASME SA209, ASTM A210/ ASME SA210, ASTM A214/ ASME SA214, ASTM A226/ ASME SA226, ASTM A250/ ASME SA250, ASTM A556/ ASME SA556, ASTM A557/ ASME SA557, A822, A334 etc.
    Material A179, A178, A192, A334-04A, A335, A209, A210, A214, A226, A250, A556, A557, A822, A334 etc.
    OD 6-530mm
    WT 0.5-30mm
    Length 0-38000mm
    Test 1. 100% PMI / SPECTRO CHEMICAL ANALYSIS TESTS 100% PMI
    2. 100% DIMENSION TESTS & 100% VISUAL EXAMINATION
    3, EDDY CURRENT OR HYDRAULIC TEST OR UTNOTES : ALL THE TESTS AND INSPECTION NEED TO PROVIDE WITH REPORTS ACCORDING TO STANDARD AND TEST RESULTS.OPTION TEST & INSPECTION ITEMS:
    1. ROUGHNESS TEST
    2. CRYSTALLING PHASE ANALYSIS
    3. INTERGRANULAR ATTACK TESTS
    4. SHIPPING NOTIFICATION BEFORE SHIPMENT

    THE DOCUMENT LSI WILL PROVIDE YOU:
    a. MTC (MATERIAL TEST CERTIFICATION) ACCORDING TO EN10204/3.1 OR EN10204/3.2;
    b. RAW MATERIAL CERTIFICATION
    c. ALL THE TEST & INSPECTION REPORTS AS PER PO AND STANDARDS
    d. HEAT TREATMENT REPORT
    e. SHIPPING NOTIFICATION BEFORE SHIPMENT
    f. QUALITY WARRANTY LETTER.

    Package In bundles, plywood cases, wooden cases with water-proof package, etc.
    Product origin Jiangsu, China(main land).
    Trade terms FOB, CIF, CFR, DDP, EXW, etc.
    Delivery Container, LCL, consignment.



    name material Size mm Thickness mm
    ms square pipe Q235 15*15 1.0 1.2 1.5
    Q235 16*16 1.0 1.2 1.5
    Q235 20*20 1.0 1.2 1.5 2.0 2.5
    Q235 25*25 1.0 1.2 1.5 2.0 2.5 2.75 3.0
    Q235 30*30 1.0 1.2 1.5 2.0 2.5 2.75 3.0
    Q235 40*40 1.2 1.5 2.0 2.5 2.75 3.0 4.0
    Q235 50*50 1.5 2.0 2.5 2.75 3.0 4.0 5.0
    Q235 60*60 2.0 2.5 2.75 3.0 4.0 6.0
    Q235 70*70 2.5 2.75 3.0 4.0
    Q235 80*80 2.0 2.5 2.75 3.0 4.0 5.0 6.0
    Q235 100*100 2.0 2.5 2.75 3.0 4.0 5.0 6.0
    Q235 120*120 3.0 4.0 5.0 6.0
    Q235 140*140 4.0 5.0 6.0
    Q235 150*150 4.0 5.0 6.0 8.0
    Q235 160*160 4.0 5.0 6.0 8.0
    Q235 180*180 4.0 5.0 6.0 8.0
    Q235 200*200 5.0 6.0 8.0 10.0
