Stainless Steel Wire Rope Manufacturer & Supplier
Short Description:
Industrial 304 and 316 stainless steel wire rope in 1×19, 7×7, 7×19 and custom constructions. Custom diameter, reel length, lay, coating, MTC and export packaging are available for marine, architectural and industrial projects.
Industrial 304/316 Stainless Steel Wire Rope – Custom Construction, Diameter & Reel Length
304 / 304L / 316 / 316L Stainless Steel Cable & Wire Rope
SAKY STEEL supplies stainless steel wire rope through a qualified manufacturing network for marine, architectural, industrial, control-cable and mechanical applications. Different grades, constructions, diameters, reel lengths, coatings and inspection requirements can be matched according to customer specifications.
|
304 / 316 / 316L
|
Custom Diameter & Length
|
Multiple Constructions
|
MTC Available
|
|
Export Packaging
|
For a fast quotation: send grade, construction, diameter, reel length, quantity and destination. |
Manufacturing Network & Production Capability
SAKY STEEL works with qualified manufacturing partners specializing in stainless steel wire, strand and wire rope production. Production resources can be selected according to material grade, rope construction, diameter, quantity, coating, testing requirements and delivery schedule.
For project orders, we coordinate technical review, production follow-up, inspection documentation, packaging and export delivery. This multi-factory supply model allows different production capabilities to be matched to different stainless steel cable requirements.
Factory Visit & Production Inspection Available
For qualified projects, customers can arrange factory visits and production inspections at the selected manufacturing facility. Third-party inspection can also be coordinated when specified before production.
Stainless Steel Wire Rope Supply Range
| Material Grades | AISI 304 / 304L / 316 / 316L |
|---|---|
| Wire Rope Constructions | 1×7 / 1×19 / 7×7 / 7×19 / 6×19 / 6×36 and Project-specific Constructions |
| Diameter | Fine Stainless Steel Cable to Industrial Wire Rope Sizes |
| Length | Cut Length / Coil / Customized Reel Length |
| Core Options | Fiber Core / Wire Strand Core / IWRC Where Applicable |
| Surface & Coating | Bright / Lubricated / PVC Coated / Nylon Coated / Customized |
| Reference Standards | ISO 3444:2023 for stainless-steel wire ropes; ASTM A492 for stainless rope wire; applicable customer, EN or DIN specifications |
| Supply Form | Coils / Plastic Spools / Plywood Reels / Wooden Reels / Cut Lengths |
| Quality Documents | MTC / Inspection Documentation / Additional Testing When Specified |
Custom Stainless Steel Wire Rope Manufacturing
Custom stainless steel cable can be supplied according to drawings, technical specifications or application conditions. The following parameters can be reviewed before production.
| Custom Option | Available Selection |
|---|---|
| Material | 304 / 304L / 316 / 316L |
| Construction | 1×7 / 1×19 / 7×7 / 7×19 / 6×19 / 6×36 / Customized |
| Diameter | Customized According to Specification and Production Feasibility |
| Length | Cut Length / Coil / Customized Reel Length |
| Lay | Lay Direction and Rope Configuration According to Specification |
| Coating | Bare / PVC / Nylon / Other Agreed Coating |
| Performance | Working Load / Minimum Breaking Load When Specified |
| Packaging | Coil / Plastic Spool / Plywood Reel / Wooden Reel / Export Pallet |
| Inspection | MTC / Dimensional Inspection / Mechanical Testing / Third-party Inspection When Specified |
Stainless Steel Wire Rope Manufacturing Process
Stainless steel wire rope production involves controlled processing from wire preparation to final rope closing, inspection and packaging. Production parameters are selected according to material grade, rope construction, finished diameter, flexibility, load requirement and application environment.
| Process | Production Control |
|---|---|
| Wire Drawing | Wire diameter and surface condition are controlled according to the required rope specification. |
| Stranding | Individual wires are formed into strands according to the specified construction and lay requirements. |
| Rope Closing | Strands are combined to produce the required finished rope construction, diameter and flexibility. |
| Coating | PVC, nylon or other specified coatings can be reviewed according to the application. |
| Rewinding & Cutting | Wire rope can be supplied in customized reel lengths, coils or cut lengths. |
| Final Inspection | Material, construction, diameter, length, surface condition and specified performance requirements are checked before shipment. |
Production & Inspection Capability
Wire Drawing
Diameter preparation and wire processing
Stranding
Multi-wire strand production
Rope Closing
Finished rope construction forming
Rewinding
Customized coil and reel lengths
Dimensional Inspection
Diameter and length verification
Mechanical Testing
Tensile or breaking-load testing when specified
Wire Rope Construction Options
1×19 — Low Stretch
High stiffness and dimensional stability for standing rigging, architectural cable and straight tension applications.
7×7 — Balanced
Balanced strength and flexibility for general cable, control systems and architectural applications.
7×19 — Flexible
Higher flexibility for pulleys, winches, running cable and applications involving repeated bending.
Other constructions such as 1×7, 6×19 and 6×36 can be reviewed according to required diameter, working load, minimum breaking load, flexibility and service conditions.
304 vs 316 Stainless Steel Wire Rope
| Grade | Main Characteristic | Typical Selection |
|---|---|---|
| 304 | Good general corrosion resistance with economical material cost | Industrial, architectural and general outdoor applications |
| 316 / 316L | Improved resistance to chloride-containing and marine environments | Marine, coastal, chemical and more corrosive applications |
Wire Rope Inspection & Quality Control
Inspection is carried out according to the ordered wire rope specification. Material grade, dimensions, construction and specified performance requirements can be verified before shipment.
| Inspection Item | Purpose |
|---|---|
| Material Verification | Confirm stainless steel grade and material traceability |
| Diameter Inspection | Verify finished wire rope diameter and tolerance |
| Construction Inspection | Verify strand arrangement, lay and rope construction |
| Tensile / Breaking Load | Available according to ordered performance requirements |
| Surface Inspection | Check rope surface, coating and visible condition |
| Documentation | MTC and agreed inspection documents |
Stainless Steel Wire Rope Applications
| Marine
Rigging, yacht cable and dock equipment |
Architecture
Cable railing and tension systems |
Industrial
Mechanical and control cable systems |
| Lifting
Hoisting and handling applications |
Safety
Guard cable, netting and barriers |
Agriculture
Support and tension cable systems |
Wire Rope Packaging & Global Delivery
Stainless steel wire rope can be supplied on plastic spools, plywood reels, wooden reels, coils or export pallets. Packaging is selected according to rope diameter, unit length, reel size, gross weight and transportation requirements.
Moisture protection, identification labels, reel direction, material information and special handling marks can be added according to confirmed order requirements.
 |
 |
 |
 |
 |
 |
Packaging can be adapted to reel diameter, unit length, gross weight and shipping method.
Product Categories
| 304 Wire Rope
General industrial and architectural applications |
316 Wire Rope
Marine and corrosion-resistant applications |
PVC / Nylon Coated Cable
Protected and application-specific cable systems |
| 1×19 Wire Rope
Low-stretch and standing rigging applications |
7×7 Wire Rope
Balanced strength and flexibility |
7×19 Wire Rope
Flexible cable for repeated bending |
Information Needed for an Accurate Quote
Material grade: 304 / 304L / 316 / 316L
Construction: 1×19 / 7×7 / 7×19 / 6×19 / 6×36 / Other
Diameter: Finished wire rope diameter
Length: Unit length and total quantity
Load requirement: Working load or minimum breaking load if applicable
Lay direction: Right / Left / Regular / Lang lay if specified
Coating: Bare / PVC / Nylon / Other
Application: Marine / Architectural / Industrial / Lifting / Other
Destination: Port / Country
Documentation: MTC / Inspection / Third-party requirements
Frequently Asked Questions
Can you supply custom diameters and reel lengths?
Yes. Diameter, unit length, reel size and total quantity can be reviewed according to the required wire rope construction and application.
Can stainless steel wire rope be supplied with PVC or nylon coating?
Yes. Please provide the required coating material, finished diameter, color, working temperature and environmental conditions for review.
Do you provide MTC and inspection documents?
Yes. Material certificates and inspection documentation can be supplied according to confirmed order requirements. Additional third-party inspection can be arranged when specified before order.
Can customers visit the manufacturing facility?
Yes. For qualified projects, factory visits and production inspections can be arranged at the selected manufacturing facility according to order requirements and production scheduling.
Which wire rope construction is suitable for pulleys?
Flexible constructions such as 7×19 are commonly considered for repeated bending, but the correct selection depends on sheave diameter, working load, speed, fatigue cycles and service environment.
Should I choose 304 or 316 stainless steel wire rope?
304 is commonly used for general industrial and architectural applications, while 316 or 316L is usually preferred for marine, coastal and chloride-containing environments requiring improved corrosion resistance.
What information should I send for a quotation?
Please provide material grade, rope construction, diameter, length, quantity, load requirement, coating, application, destination and required inspection documents.
Get a Stainless Steel Wire Rope Quote
Send your drawing or specification. SAKY STEEL will review the material grade, construction, diameter, load, packaging and delivery requirements before confirming the offer.
