Stainless Steel Corrugated Pipe


  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Port: Shanghai Ningbo Shenzhen
  • Payment Terms: L/C,D/A,D/P,T/T
  • Product Detail

    Product Tags

    304 stainless steel corrugated pipe tube

    Grade C% Si% Mn% P% S% Cr% Ni% Mo% Cu%
    304 =0.08 =1.0 =2.0 =0.045 =0.03 18.0-20.0 8.0-10.0 -
    T*S Y*S Hardness Elongation
    (Mpa) (Mpa) HRB HB (%)
    =520 =205 =40

    Specifications of stainless steel corrugated pipe:

    A.Product Description
    Product Name stainless steel corrugated hose
    Item No. PT0101
    Basic Features 1) DN: 12-32MM, Length:10-50M.
    2) Thickness: 0.2mm-0.25mm
    3) Hose ripple : shallow annular corrugation
    4) Hose material: SS304, SS316L.
    5) Max working pressure: 12 bar
    6) Nut: Brass fitting or Stainless steel fitting
    Application Water, Gas, Oil and other liquid supply.
    Sample Time a). 1 day for our sample stock available.
    b). 3-5 days for customized.
    connects firmly
    has long performance life
    high flexible
    the yellow PE coating make the hose more attractive and easy to wash
    reliable and safe
    C.Specifications
    DN ID*OD size Thickness Material Pipe ripple
    12mm ID12 x OD16mm 0.2 / 0.25mm SUS304/316L Annular wave
    16mm ID16 x OD20mm 0.2 / 0.25mm SUS304/316L Annular wave
    20mm ID20 x OD25mm 0.2 / 0.25mm SUS304/316L Annular wave
    25mm ID25 x OD32mm 0.2 / 0.25mm SUS304/316L Annular wave
    32mm ID32 x OD42mm 0.2 / 0.25mm SUS304/316L Annular wave
    Pipe Diameter DN1/2-32inch (DN12-800mm)
    Pipe Material SS321, 304, 316, 316L
    Pipe Type Annular corrugated pipe
    Pipe thickness 0.28-1.0mm
    Braided mesh material SS304
    Braided mesh layer single layer or double layers or three layer
    Max. woking pressure 10Mpa~35MPa
    Working temperature (-200)~(+800) °c
    Connect type Flange, nuts, fast fittings,
    Standard GB/T14525-2010, ANSI,JIS,DIN,GOST
    Flange material stainless steel or alloy nickle
    Pipe assembly length according to clients’ requirements
    NO. DN ID OD Pitch distance Wall thickness theoretical weight
    (KG/M)
    1 12 11.6 18 3 0.2 0.17
    2 15 14.4 21.5 3.5 0.3 0.28
    3 18 17.4 25.5 3.5 0.3 0.34
    4 20 19.4 27 4.5 0.3 0.38
    5 25 24.4 32.5 5 0.3 0.46
    6 32 31.4 40 5.5 0.3 0.6
    7 40 39.4 50 6 0.3 0.75
    8 50 49.4 63 7.5 0.3 0.9
    9 65 64.4 81 9 0.3 1.6
    10 80 79.2 98 10.5 0.4 2
    11 100 99.2 120 13 0.4 2.6
    12 125 124 150 14.5 0.5 3.9
    13 150 149 180 17.5 0.5 4.3
    14 200 198.8 240 24 0.6 6.8
    15 250 248.4 300 28 0.8 11
    16 300 298 355 33.5 1 17.5
    17 350 348 410 35 1 20
    18 400 397.6 460 40 1.2 25
    19 450 447.6 489 45 1.2 29
    20 500 497.6 545 45 1.2 33.5
    21 600 597.6 650 50 1.2 40.5



    Applications:

    Iron & steel industry/ Petroleum& gas plants/ Chemistry industry/ Heating&cooling systems/ Food industry/ Automotive industry/ Paper production plants/ Maritime industry/ Defense industry/ Moving systems/ Any kind of depot and tank connections.
